ESPECIFICACION
CPU:
º Onboard Intel Single Core Atom D425 processor
º DMI 667Mb/s
CHIPSET: Intel® NM10 Express
GRAFICOS:
º Integrated Intel® Graphics Media Accelerator 3150(GMA3150)
º Integrated DirectX 9 graphics processor
º Max DVMT Graphics Memory up to 384MB
MEMORIA PRINCIPAL:
º Single-channel DDR3 memory architecture
º 2 x 240-pin DDR3 DIMM socket support up to 4GB
º Support DDR3 800 SO DIMM
Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS.
For Windows® 64-bit OS with 64-bit CPU, there is no such limitation
RANURA DE EXPANSION: 1 x PCI slot
ALMACENAMIENTO:
º Support by Intel® NM10 Express
? 2 x Serial ATA 3.0Gb/s devices
AUDIO:
º Realtek ALC662 6-channel HD audio CODEC
º Compliant with HD audio specification
LAN:
º Realtek 8105E 10/100 Lan
º Realtek 8111E Giga Lan (Optional)
PANEL DE E/S TRASERO:
º 1 x PS/2 keyboard & PS/2 mouse connectors
º 1 x D-sub(VGA)
º 1 x Serial port (COM1)
º 1 x Parallel Port
º 1 x RJ45 LAN connector
º 1 x Audio port (Line-in, Line-out, Mic-in)
º 4 x USB 2.0 Ports
CONECTORES Y HEADERS DE E/S INTERNOS:
º 1 x 24-pin ATX Power Supply connector
º 1 x 4-pin CPU_FAN connector
º 1 x Front panel switch/LED header
º 1 x Front panel audio header
º 1 x Clear CMOS header
º 2 x USB 2.0 headers support additional 4 USB 2.0 Ports
º 1 x 4-pin SYS_FAN connector
º 2 x SATA 3Gb/s connectors
BIOS DEL SISTEMA:
º AMI BIOS with 8Mb SPI Flash ROM
º Supports Plug and Play, STR (S3) / STD (S4) , Hardware monitor, Multi Boot
º Audio, LAN, can be disabled in BIOS
º F11 hot key for boot up devices option
º Support eJIFFY
FORMATO: Mini ITX 170x170mm
